Customized Precision NdFeB Magnets Specifications:
Materials
NdFeB, Grade: N30-N55, N30M- 52M, N30H-52H,N30SH-48SH,30UH-42UH,28EH-40EH,N28AH-35AH
Shape
Disc, Cylinder, Block, Ring, Countersunk, Segment, Trapezoid, Irregular shapes and more. Customized shapes for Neodymium Magnets are available.
Dimensions
Radius: 3.64mm
Width: 5.54mm
Thickness: 1.24mm
Accept Customized
Tolerances
Radius: -0.04 to +0.04mm
Width: -0.1 to +0.06mm
Thickness: -0.03 to +0.03mm
Accept Customized
Coating
Ni-Cu-Ni, Nickel, Zn, Gold, Silver, Copper, Epoxy, Chemical, PTFE, Parylene, Everlube, Passivation and more
Capacity
more than 10K pieces/month
Application
motors
Different magnet wide application, our company can according to user’s different product requirements, micro users customize various special magnet. The lowest tolerance of + / – 0.04 mm, may choose samarium cobalt, ndfeb, etc as raw materials.
Introduction
Neodymium Magnets are widely used in many fields, such as motors, sensors,microphones, wind turbines, wind generators, VCMs in hard disk drives, printer,switchboard, loudspeakers, magnetic separation, magnetic hooks, magnetic holder,magnetic chuck, common daily use, and so on.
Specially-shaped magnets have been widely applied. Our company can customize various specially-shaped magnets for users according to their different product requirements. Samarium cobalt, NdFeB and other materials can be used as raw materials at the lowest tolerance of ±0.02mm.
Product Details | |||||
Project | Long（mm） | Width（mm） | Height（mm） | Vertical degree | Material |
Basic Dimensions | 0.5-3.0 | 0.5-3.0 | 0.5-3.0 | Custom | SmCo, NdFeB, Ferrite, AlNiCo, Ceramic and etc. |
Tolerance | ±0.005-±0.02 | ±0.005-±0.02 | ±0.005-±0.02 | ±3° | |
Neodymium magnets (Nd-Fe-B) are made from the most powerful magnetic material in the world. They boast extreme strength in a small size. We offer many sizes and grades suitable to a variety of manufacturing, hobby and craft applications.
These Micro Neodymium magnets are little bigger than a watch battery but have an astonishing pull of 0.12lb. Every magnet has a triple coating of Nickel, copper and Nickel again to prevent against corrosion. Our Neodymium magnets are typically used in computer hard drives, audio speakers, electronics and medical fields. They also have many uses in engineering and manufacturing where small size and maximum strength are required. What’s more, they are ideal for creating a shock-absorbing or damping effect because of their resistance to demagnetization.
Request a custom magnet quote, Please contact MPCO Magnet.
Custom Magnets and Assemblies: Precision Micro Neodymium Magnets
Design → Simulation → Prototype → Production
Manufacturing capacity: Heeger Magnet can produce custom magnets in large volumes and retain inventory for just in time delivery. HM can also produce plastic or metal parts with embedded magnets.
Custom magnets lead time: 3-4 Weeks.
Custom plastic or metal assemblies lead time: 4-5 Weeks.
